| 모델 번호: | ZD-갈와이어 | 적용: | 울타리가 쳐지, 구조를 제조하면서, 네트로 이루어지면서, 패키징하면서, 실처럼 늘어지세요 |
|---|---|---|---|
| 합금 또는 아니: | 맞춤형 | 표준: | BS, JIS, GB, ASTM, DIN, AISI |
| 소재: | ASTM A36 A572 A992 S235jr/J0/J2 S355jr/J0/J2 | 맞춤형: | 그래요 |
| 맞춤형 사이클: | 7~15일 | 제품 이름: | 아연 도금 강선 |
| 지불 기간: | 30%T/T는 + 70% 균형을 진보시킵니다 | 모크: | 3 톤 |
| 길이: | 맞춤형 | 장점: | 내마모성, 가공성, 용접 용이성 |
| Specification2: | Zd-갈와이어5 6 7 8 9 10 | 사양3: | Zd-갈와이어12 14 15 16 18 |
| 표준1: | ASTM a 6/a 6m-07 BS 4-1:1993 En 10024 JIS G 3192 | 운송 패키지: | 표준 패키지 내보내기/요청으로 |
| 사양: | 고객 요구에 따라 | 상표: | 정더 |
| 원산지: | 중국 | HS 코드: | 7217200000 |
| 공급 능력: | 50000 톤 / 달 | ||
| 강조하다: | 진열제 철선 0.7mm,진열제 철선 0.8mm,진열제철 와이어 1.2mm |
||
ZHENGDE Galvanized wire production process: It is processed by high-quality low-carbon steel wire rod, and the high-quality low-carbon steel is processed by drawing forming, pickling and derusting, high-temperature annealing, hot-dip galvanizing and cooling.
Galvanized wire characteristics: Galvanized iron wire has good toughness and elasticity, and the highest amount of zinc can reach 300 grams per square meter. It has the characteristics of thick galvanized layer and strong corrosion resistance.
Galvanized wire application: The products are widely used in various fields such as construction, handicrafts, weaving wire mesh, highway guardrails, product packaging and daily civilian use.
Galvanized wire is further divided into hot-dip galvanized wire and cold-dip galvanized wire (electro-galvanized wire), which are distinguished as follows:
Hot-dip galvanizing is dip-plating in a heated and melted zinc solution. The production speed is fast, and the coating is thick but uneven. The minimum thickness allowed by the market is 45 microns, and the maximum thickness can reach more than 300 microns. The color is darker, consumes more zinc metal, forms an infiltration layer with the base metal, and has good corrosion resistance. Hot-dip galvanizing can last for decades in outdoor environments.
Cold galvanizing (electrogalvanizing) is to gradually coat the metal surface with zinc through the unidirectional current in the electroplating tank. The production speed is slow, the coating is uniform, and the thickness is thin, usually only 3-15 microns. The appearance is bright and the corrosion resistance is poor. It usually rusts in a few months.
Compared with hot-dip galvanizing, the production cost of electro-galvanizing is lower.
| Gauge | SWG | BWG | AWG | Metric system | ||||
| in | mm | in | mm | in | mm | mm | kg/km | |
| 0 | 0.324 | 8.23 | ||||||
| 1 | 0.3 | 7.02 | ||||||
| 2 | 0.276 | 7.01 | ||||||
| 3 | 0.252 | 6.401 | 0.259 | 6.58 | 0.2294 | 5.83 | ||
| 4 | 0.232 | 5.893 | 0.238 | 6.05 | 0.2043 | 5.19 | 6 | 220 |
| 5 | 0.212 | 5.385 | 0.22 | 5.59 | 0.1819 | 4.62 | 5.5 | 185 |
| 6 | 0.192 | 4.811 | 0.203 | 5.16 | 0.162 | 4.11 | 5 | 153 |
| 7 | 0.176 | 4.47 | 0.18 | 4.57 | 0.1443 | 3.67 | 4.5 | 124 |
| 8 | 0.16 | 4.064 | 0.165 | 4.19 | 0.1285 | 3.26 | 4 | 98 |
| 9 | 0.144 | 3.658 | 0.148 | 3.76 | 0.1144 | 2.91 | 3.5 | 95 |
| 10 | 0.128 | 3.251 | 0.134 | 3.4 | 0.1019 | 2.59 | 3.2 | 62 |
| 11 | 0.116 | 2.946 | 0.12 | 3.05 | 0.09074 | 2.3 | 2.9 | 51 |
| 12 | 0.104 | 2.642 | 0.109 | 2.77 | 0.08081 | 2.05 | 2.6 | 41 |
| 13 | 0.092 | 2.337 | 0.095 | 2.41 | 0.07196 | 1.83 | 2.3 | 32 |
| 14 | 0.08 | 2.032 | 0.083 | 2.11 | 0.06408 | 1.63 | 2 | 24 |
| 15 | 0.072 | 1.829 | 0.072 | 1.83 | 0.05707 | 1.45 | 1.8 | 20 |
| 16 | 0.064 | 1.626 | 0.065 | 1.65 | 0.05082 | 1.29 | 1.6 | 16 |
| 17 | 0.056 | 1.422 | 0.058 | 1.47 | 0.04526 | 1.15 | 1.4 | 12 |
| 18 | 0.048 | 1.219 | 0.049 | 1.24 | 0.0403 | 1.02 | 1.2 | 8 |
| 19 | 0.04 | 1.016 | 0.042 | 1.07 | 0.03589 | 0.91 | 1 | 6 |
| 20 | 0.036 | 0.914 | 0.035 | 0.89 | 0.03196 | 0.812 | 0.9 | 5 |
| 21 | 0.032 | 0.873 | 0.032 | 0.81 | 0.02846 | 0.723 | 0.711 | 3.2 |
| 22 | 0.028 | 0.711 | 0.028 | 0.71 | 0.02535 | 0.644 | 0.558 | 3.1 |
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Middle East region, Russia, Africa, North America, and other parts of the world.
Company Philosophy:
Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.
If you encounter dishonest manufacturers during the procurement process, we can provide you with a professional legal team. We hope our cooperation is full of sunshine!
Welcome to the company for investigation and cooperation, and look forward to friendly cooperation with you!
Thank you for your support to our company. We are pleased to receive your inquiry and will reply to you as soon as possible.
